7 Position Female Circular Connector Receptacle Housing Free Hanging (In-Line)

Specifications

  • Series: CPC Series 1
  • Connector Type: Receptacle Housing
  • Type: For Female Sockets
  • Number of Positions: 7
  • Shell Size - Insert: 13-7
  • Shell Size, MIL: n/a
  • Contact Type: Crimp
  • Contact Size: 16
  • Mounting Type: Free Hanging (In-Line)
  • Mounting Feature: n/a
  • Fastening Type: Threaded
  • Orientation: A
  • Shell Material: Polyamide (PA66), Nylon
  • Shell Finish: n/a
  • Housing Color: Black
  • Ingress Protection: n/a
  • Material Flammability Rating: UL94 V-0
  • Features: n/a
  • Shielding: Unshielded
  • Note: Contacts Not Included
  • Includes: n/a
  • Insert Material: Thermoplastic
  • Contact Shape: Circular
  • Operating Temperature: -55°C to 105°C
  • Base Number: 211398

Product Identification

Manufacturer Series:211398

Dimensions & Appearance

Mounting:Cable Mount
Body Orientation:Straight

Features

Number of Ports:1
Number of Terminals:7
Contacts Classification:7Signal
Shell Size:13-7
Number of Contacts:7
Contact Material:N/A
Contact Gender:SKT
Gender:Female
Contact Plating:N/A
,
