60W Regulated Single Output DC-DC Converter


Output: 12 Volts @ 5 Amps

Features:

  • Input voltage range: 36-75VDC
  • 2:1 wide input range
  • High efficiency: 92%
  • 1500VDC I/O isolation
  • Built-in remote ON / OFF control
  • Built-in remote sense
  • Trimming output 10%
  • Comply with CE / FCC without external components
  • Protections: Short circuit / Overload / Input and output Over voltage
  • Cooling by free air convection
  • Six-sided shield metal case
  • 100% burn-in test
  • Low cost / High reliability
  • Size: 2.0"L x 2.0"W x 0.43"H
  • Weight: 0.15 lbs.

    • Product Identification

    Product Type:DC to DC Regulated Single Output Converter SMPS
    Manufacturer Series:SKA60

    Dimensions & Appearance

    Height:0.43 in.
    Color:Silver
    Width:2 in.
    Length:2 in.
    Mounting:Encapsulated

    Operating conditions

    Minimum Operating Temperature:-40°C
    Maximum Operating Temperature:70°C

    Packaging

    Package:Enclosed Module

    Input

    Input Voltage Range:36 VDC to 75 VDC
    Maximum Input Current:1.37 A

    Output

    Number of Outputs:1
    Output Voltage:12 VDC
    Output Connector Type:PC Pins
    Additional Output Voltages (VDC):N/A
    Output Current:5 A

    Features

    Pins:8
    Efficiency:92%
    Power Rating:60 W
    ,
