Features
- Compliant with IEEE802.3bt Standard
- Compliant with Phihong Proprietary 12.5K Detection
- 4 Pair Powering +3, 4, 5, 6 / -1, 2, 7, 8
- Non-Vented Case
- Multi-Gigabit Data Rates (1G, 2.5G, 5G, 10G) models available
- DoE Level VI Compliant
- ErP/Ecodesign Directive 2009/125/EC - Regulation EU 2019/1782 Compliant
- Full Protection OCP, OVP
- Limited Power Source (LPS)
- 1-year Warranty
Overview
Applications
- IP telephones
- Wireless Network Access Points
- Security Cameras
- Bluetooth® Access Points
- WiMAX® Access Points
Product Identification
Type:Auto Switching SMPS
Manufacturer Series:POE60U
Compliance
Agency Approvals: CE, UKCA, CUL
Dimensions & Appearance
Style:Desktop
Color:Black
Height:1.42 in.
Width:2.56 in.
Length:6.43 in.
Operating conditions
Minimum Operating Temperature:-10°C
Maximum Operating Temperature:60°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:100 VAC to 240 VAC
Maximum Input Current:2 A
Output
Number of Outputs:1
Output Connector Diameters:N/A
Output Current (Channel 1):1.07 A
Output Connector Type:RJ45
Output Voltage (Channel 1):56 VDC
Output Voltage:56 VDC
Additional Output Voltages (VDC):N/A
Output Current:1.07 A
Features
Polarity:Center Positive
IP Rating:IP40
Product Note:Level VI
AC Power Cord:NOT INCLUDED, RECOMMEND 2271575
Minimum Isolation Voltage:6000V
Efficiency:88%
Power Rating:60 W
