600W Low-Profile Energy-Efficient Medical Open Frame Power Supply 48V 8.3A Convection 12.5A with Fan

Features

  • MEAN WELL Patent Number: ZL 202223277512.1
  • 5" x 3" compact size with low-profile (33.5mm)
  • 80-264VAC wide input range with PFC, No load power consumption <0.5W
  • Global certification in multiple fields:
    • ITE 62368-1
    • Medical 60601-1
    • Household 60335-1
    • Industrial 61558-1/-2-16
  • 150% peak load for 3 seconds
  • ~400W convection, 600W with fan (23 CFM fan forced-cooled, like P/N: 2342799)
  • Suitable for Class I or Class II installations
  • Over voltage category III (OVC III)
  • -40 to +80°C wide range operation temperature
  • High efficiency
  • Protections: Short circuit / overload / over voltage / over temperature
  • Extremely low leakage current, 2x MOPP, suitable for BF medical applications
  • Operating altitude up to 5000 meters
  • Built-in 12V/0.5A for external fan (fan not included)
  • Built-in Remote sense
  • 3-year warranty

Overview

LOP-600 is a 600W highly reliable energy-efficient PCB type low-profile power supply with a high-power density (30.3W/in³) in a 5"x3" footprint. It accepts 80 to 264 VAC input voltage and offers various output voltages 12V and 54V.

The main feature of the LOP-600 include low standby power (<0.5W), high efficiency, capability of providing 320W under natural air cooling and 500W with an additional fan (sold separately). It has a 150% for 3 seconds overload capacity, a wide operating temperature range of -40 to 80°C, compliance with OVCIII, suitable for Class I (with FG) or Class II (without FG) systems. The power supply has obtained multiple safety certifications including 62368-1, 60601-1, 61558-1, 60335-1, and is designed to meet 2xMOPP with extremely low touch leakage current <70µA making it suitable for class medical devices. With high product safety and excellent EMC performance, it is versatile and applicable in various fields such as ITE, medical, industrial control, home automation and more. It is a cost-effective, slim, open-frame type power supply.

Applications

  • Industrial automation machinery
  • Industrial control system
  • Security system
  • Mechanical and electrical equipment
  • Electronic instruments, equipment, or apparatus
  • Network equipment and Telecom devices
  • Power sourcing equipment of PoE
  • Home automation
  • Medical devices

Product Identification

Type:Auto Switching SMPS
Product Type:Green Medical AC to DC Power Supply SMPS
Manufacturer Series:LOP-600

Compliance

Agency Approvals: CB, CCC, CE, C-TICK, CUL, EAC, EN, TUV, UKCA, UL, 60335-1, 60601-1, 61558-1/-2-38, ITE 62368-1

Dimensions & Appearance

Color:a, n
Style:Medical Open Frame
Height:1.32 in.
Width:3 in.
Length:5 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:80°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:80 VAC to 264 VAC
Maximum Input Current:6.4 A

Output

Number of Outputs:1
Output Connector Diameters:M3.5
Output Connector Type:Screw Terminals
Output Voltage:48 VDC
Additional Output Voltages (VDC):N/A
Output Current:12.50 A

Features

PFC Function:Yes
Minimum Isolation Voltage:4000V
AC Power Cord:NOT INCLUDED
Efficiency:95%
Power Rating:600 W
,
