60 mm x 60 mm x 38 mm Tube Axial Fan 24 VDC Ball Bearing 86CFM 66dBA 12" Wires (4)

Features

  • Voltage Rating: 24 VDC
  • Height: 60 mm
  • Width: 60 mm
  • Depth: 38 mm
  • Air Flow (CFM): 86
  • Bearing: Ball
  • Current Rating: 1250 mA
  • Power Rating: 30 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 66
  • Termination: 12" Wires (4)
  • Product Type: 60mm x 60mm DC Fan
  • Speed: 16000 rpm
  • Maximum Pressure: 2.95 in.
  • Additional Features: Open Collector Tach Output and PWM
  • Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Electronically Protected, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 16000 rpm.

Product Identification

Additional Feature:Open Collector Tach Output, PWM
Product Type:DC Fan

Compliance

RoHS Status:ROHS Compliant
Compliance:Compliance Docs
Agency Approvals: CE, CUL, TUV, UKCA, UL

Dimensions & Appearance

Depth:38 mm
Height:60 mm
Width:60 mm

Features

Bearing:Ball
Motor Drive Type:Brushless DC, Auto Cutoff, Auto Restart, Electronically Protected, Polarity Protected
Voltage Rating:24 VDC
Noise (dBA):66
Maximum Pressure:2.95 in.
Air Flow (CFM):86
Termination:12" Wires (4)
Speed:16000 rpm
Power Rating:30 W
Current Rating:1250 mA
,
