60 mm x 60 mm x 20 mm Tube Axial Fan 24 VDC Ball Bearing 22.8CFM 33.4dBA 12" Wires (3)

Features

  • Voltage Rating: 24 VDC
  • Height: 60 mm
  • Width: 60 mm
  • Depth: 20 mm
  • Air Flow (CFM): 22.8
  • Bearing: Ball
  • Current Rating: 150 mA
  • Power Rating: 3.6 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 33.4
  • Termination: 12" Wires (3)
  • Product Type: 60mm x 60mm DC Fan
  • Speed: 5550 rpm
  • Maximum Pressure: 0.2 in.
  • Additional Features: Open Collector Alarm Output
  • Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Polarity Protected, Electronically Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 5550 rpm.

Product Identification

Additional Feature:Open Collector Alarm Output
Product Type:DC Fan

Compliance

RoHS Status:ROHS Compliant
Compliance:Compliance Docs
Agency Approvals: CE, CUL, TUV, UKCA, UL

Dimensions & Appearance

Depth:20 mm
Height:60 mm
Width:60 mm

Features

Bearing:Ball
Noise (dBA):33.4
Air Flow (CFM):22.8
Maximum Pressure:0.2 in.
Motor Drive Type:Brushless DC, Auto Cutoff, Auto Restart, Polarity Protected, Electronically Protected
Voltage Rating:24 VDC
Speed:5550 rpm
Power Rating:3.6 W
Termination:12" Wires (3)
Current Rating:150 mA
,
