5V 200mA 1W Regulated Encapsulated DC-DC Converter 36-75V Input

5 Volts DC @ 20-200 mA

Specifications

  • Input voltage range: 36 to 75 V
  • Output current range: 20 mA to 200 mA
  • Size: 0.69" x 0.3" x 0.44"
  • Pins: 4
  • SIP package
  • 2:1 wide input range
  • Line regulation: ±0.5
  • Load regulation: ±0.5%
  • Ripple & noise: 60 mVp-p
  • 1500 VDC I/O isolation
  • Built-in EMI filter without external components
  • Cooling by free air convection
  • Protections: Short circuit, overload
  • 100% burn-in test
  • Low cost / high reliability
  • 2 year warranty

Product Identification

Product Type:DC-DC Regulated Single Output Converter SMPS
Manufacturer Series:SPA01

Dimensions & Appearance

Height:0.44 in.
Width:0.30 in.
Length:0.69 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:90°C

Input

Maximum Input Current:0.027 A
Input Voltage:48 VDC
Input Voltage Range:36 VDC to 75 VDC

Output

Number of Outputs:1
Output Voltage:5 VDC
Output Current:0.20 A
Output Connector Type:PC Pins
Additional Output Voltages (VDC):N/A

Features

Pins:4
Efficiency:77%
Power Rating:1 W
,
