54V 1.77A 96W Single Output Industrial AC-DC Switching Power Supply

54 Volts @ 1.77 Amps HEP-100 is a 100W industrial AC-DC power supply featuring outstanding capability to operate under highly humid, dusty, oily, and high-vibration harsh environments. The entire series is housed with the aluminum case and fully potted with heat-conducted silicone.

Features:

  • Universal AC input/full range
  • Built-in active PFC function
  • High efficiency up to 93%
  • Fanless design, cooling by free air convection
  • -55 to +70°C wide operating range
  • Aluminum case and filling with heat-conducted silicone
  • IP65 design
  • Meet 6kV surge immunity level
  • Withstand 10G vibration test
  • Protections: Short circuit, overload, over voltage, over temperature
  • Operating altitude up to 16,400 feet (5000 meters)
  • 6 year warranty

Applications:

  • Outdoor telecommunication equipment
  • Outdoor electronic signage and billboards
  • Petroleum plant or mine shaft facility

Product Identification

Type:Auto Switching SMPS
Manufacturer Series:HEP-100

Compliance

Agency Approvals: CB, CE, CUL, EAC, EN, UL

Dimensions & Appearance

Style:Enclosed
Color:Silver
Height:1.53 in.
Width:2.68 in.
Length:8.66 in.

Operating conditions

Minimum Operating Temperature:-55°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 305 VAC
Maximum Input Current:1.2 A

Output

Number of Outputs:1
Output Current (Channel 1):1.77 A
Output Voltage (Channel 1):54 VDC
Output Connector Type:Stripped and Tinned
Output Voltage:54 VDC
Output Current:1.77 A

Features

PFC Function:Yes
Minimum Isolation Voltage:3750V
Efficiency:93%
Power Rating:95.58 W
,
