50W 5V 10A DC-DC Converter DIN Rail Mount Ultra-Wide Input 150-1500VDC

Features

  • Ultra-Wide Input Voltage Range: 150 to 1500 VDC (10:1 Ultra)
  • 57mm slim width
  • 4 KV I/O high isolation (reinforced isolation)
  • Protections: Short circuit, overload, over voltage, over temperature, DC input under voltage, DC input reverse polarity
  • Cooling by free air convection
  • Can be installed on DIN rail TS-35/7.5 or TS-35/15
  • Ultra-Wide Operating Temperature Range: -30 to +80°C (>+55°C derating)
  • Over voltage category II
  • DC OK relay contact
  • DC output voltage adjustable (+20%)
  • 3 year warranty

Specifications

  • Output Voltage: 5 VDC
  • Output Voltage Adjustment Range: 5 to 6 V
  • Output Current: 0 to 10 A
  • Rated Power: 50 W
  • Input Voltage: 150 to 1500 VDC
  • Size: 2.24"W x 3.68"H x 4.13"D (57 x 93.5 x 105 mm)
  • Agency Approvals: CE, EN, EAC

Applications

  • Photovoltaic power generation (solar)
  • High voltage frequency conversion
  • Industrial control systems
  • Semiconductor fabrication equipment
  • Electromechanical apparatus
  • DC bus centralized application

Product Identification

Manufacturer Series:DDRH-60
Product Type:DC-DC Converter SMPS

Compliance

Agency Approvals:CE, EN, EAC

Dimensions & Appearance

Mounting:DIN Rail
Color:White
Width:2.24 in.
Height:3.68 in.
Length:4.13 in.

Operating conditions

Minimum Operating Temperature:-30°C
Maximum Operating Temperature:80°C

Input

Input Voltage Range:150 VDC to 1500 VDC
Input Voltage:800 VDC
Maximum Input Current:120 A

Output

Number of Outputs:1
Output Voltage (Channel 1):5 VDC
Output Voltage:5 VDC
Output Connector Type:Screw Terminal Block
Output Current (Channel 1):10 A
Output Current:10 A

Features

Minimum Isolation Voltage:4000V
Efficiency:81%
Power Rating:50 W
,
