50.4W ENCLOSED DC/DC CONVERTER

12 Volts @ 4.2 Amps


Features:

  • Input Voltage Range: 19V-36V
  • Built-in EMI filter, low ripple noise
  • 100% Full load burn-in test
  • Protections: Short-circuit, Overload, Overvoltage
  • Number of terminal pins: 5
  • Ripple & Noise: 120mVp-p
  • Size: 6.3"L x 3.8"W x 1.5"H
  • 1-year warranty

Product Identification

Type:Step Down
Product Type:DC to DC Power Supply SMPS
Manufacturer Series:SD-50

Compliance

Agency Approvals: EAC, EN, CE, CE, EN, EAC

Dimensions & Appearance

Mounting:Enclosed
Height:1.5 in.
Width:3.8 in.
Length:6.3 in.

Operating conditions

Minimum Operating Temperature:-10°C
Maximum Operating Temperature:60°C

Packaging

Package:Enclosed

Input

Input Voltage:24 VDC
Input Voltage Range:19 VDC to 36 VDC
Maximum Input Current:3 A

Output

Number of Outputs:1
Output Voltage:12 VDC
Output Connector Type:Screw Terminal Block
Additional Output Voltages (VDC):N/A
Output Current:4.20 A

Features

Pins:5
Switching Regulator:Yes
Efficiency:75%
Power Rating:50.4 W
,
