35 Watt Single Output Switching Power Supply
25-70 Volts @ 500 mAmps
Features:
- Constant current mode power supply
- Universal AC input/ Full range
- Withstand 300VAC Surge input for 5 seconds
- Protections: Short circuit/ Over voltage
- Fully isolated plastic case
- Small and compact size
- Cooling by free air convection
- IP30 design
- 100% full load burn-in test
- Suitable for LED lighting and moving sign applications
- Low cost/ High reliability
- Non-Class 2
- 2 years warranty
Product Identification
Product Type:Auto Switching SMPS
Manufacturer Series:APC-35
Compliance
Agency Approvals: EAC, EN, CE, CE, EN, EAC
Dimensions & Appearance
Style:Enclosed
Color:White
Height:1.52 in.
Width:2.67 in.
Length:8.66 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 264 VAC
Maximum Input Current:0.75 A
Output
Number of Outputs:1
Output Current (Channel 1):0.5 A
Output Voltage (Channel 1):25 VDC to 70 VDC
Output Connector Type:Stripped and Tinned
Output Current:0.50 A
Output Range:25 VDC to 70 VDC
Output Voltage:See Output Range
Features
PFC Function:No
IP Rating:IP42
Minimum Isolation Voltage:3750V
Efficiency:84%
Power Rating:35 W
