4KW True Sine Wave Inverter with AC Charger and UPS 100-120VAC Output 24VDCin
Features
- Combines AC/DC charger, DC/AC inverter, AC by-pass & support external MPPT solar charger
- AC utility charger up to 4520W
- UPS function (AC by-pass_ without interruption, transfer time <10ms
- True sine wave output (THD <3%)
- High surge power up to 10 KW
- Parallel synchronized operation up to 30KW (5+1 unit)
- Temperature controlled cooling fan
- AC output voltage and frequency selectable by DIP switch
- Protections:
- Input: Reverse polarity, DC low alarm, DC low shutdown, over voltage
- Output: Short circuit, overload, over temperature
- Battery over discharge protection (low voltage disconnect)
- -30°C to +70°C wide operating temperature
- Suitable for leave-acid or li-ion batteries
- Support MODBus-RTU (RS-485) / CANBus protocol communication
- Conformal coating
- 5-year warranty
Overview
The NTN-5K is a 4000W highly reliable off-grid true sine wave DC-AC power inverter with built-in AC charger and UPS function (AC by-pass). Its key features include: digital design with MCU control, streamlined control circuitry that quickly responds to environmental changes to improve reliability, high quality fan with low acoustic noise, 10KW peak power, adjustable AC output voltage and frequency, complete protection features, and more.
When combined with batteries, the NTN-5K series is suitable for use in residential, commercial, marine, automobile, mine, construction site, and remote areas with no access to utility power, and the output can be used to power fans, TV, radio, phone charger, PC/laptop, lighting, induction stove, air conditioner, electromechanical tools, communications equipment, power distribution cabinet, outdoor camping equipment, marine AC power, factory equipment, and more.
