25 Watt Single Output Switching Power Supply

48 Volts @ 0.53 Amps

Features:

  • Universal AC input/ Full range (up to 305VAC)
  • Protections: Short circuit/ Overload/ Over voltage/ Over temperature
  • Built-in active PFC function
  • Cooling by free air convection
  • Fully isolated plastic case
  • Fully encapsulated with IP67 level
  • Class II power unit, no FG
  • Class 2 power unit
  • Built-in 3 in 1 dimming function (1~10Vdc or PWM signal or resistance)
  • Suitable for LED lighting and moving sign applications
  • Compliance to worldwide safety regulations for lighting
  • Suitable for dry/ damp/ wet locations
  • 3 years warranty

Product Identification

Product Type:Auto Switching SMPS
Manufacturer Series:LPF-25D

Compliance

Agency Approvals: CB, CCC, CE, CUL, EAC, EN, ENEC, UL, UL, CUL, CB, CE, EN, ENEC, EAC, CCC

Dimensions & Appearance

Style:Enclosed
Color:White
Height:1.3 in.
Width:1.6 in.
Length:5.8 in.

Operating conditions

Minimum Operating Temperature:-35°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 305 VAC
Maximum Input Current:0.4 A

Output

Number of Outputs:1
Output Connector Type:Stripped and Tinned
Output Current:0.53 A
Output Voltage:48 VDC
Output Range:26.4 VDC to 48 VDC

Features

PFC Function:Yes
Minimum Isolation Voltage:3750V
IP Rating:IP67
Efficiency:86%
Power Rating:25.44 W
,
