48V 8.3A 400.8W Enclosed Switching Power Supply
48 Volts DC @ 8.3 AmpsFeatures- Universal AC input / full range ( 90-264 VAC @ 47-63 Hz)
- Withstand 300VAC surge input for 5 seconds
- Ripple & Noise: 240 mVp-p
- High efficiency: 91%
- Built-in active PFC function
- Design against rain splash
- Protections: Short circuit, overload, over voltage, over temperature
- Cooling by free air convection
- LED indicator for power on
- Low cost, high reliability
- 100% full load burn-in test
- 3 year warranty
Applications
- LED strip lighting
- LED channel letters
- LED moving sign
- Universal AC input / full range ( 90-264 VAC @ 47-63 Hz)
- Withstand 300VAC surge input for 5 seconds
- Ripple & Noise: 240 mVp-p
- High efficiency: 91%
- Built-in active PFC function
- Design against rain splash
- Protections: Short circuit, overload, over voltage, over temperature
- Cooling by free air convection
- LED indicator for power on
- Low cost, high reliability
- 100% full load burn-in test
- 3 year warranty
Applications
- LED strip lighting
- LED channel letters
- LED moving sign
Product Identification
Type:Auto Switching SMPS
Manufacturer Series:ERPF-400
Compliance
Agency Approvals: CB, CCC, CE, CUL, EAC, EN, TUV, UL
Dimensions & Appearance
Style:Enclosed
Color:Silver
Height:1.89 in.
Width:5.12 in.
Length:8.68 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:60°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 264 VAC
Maximum Input Current:2.5 A
Output
Number of Outputs:1
Output Voltage (Channel 1):48 VDC
Output Connector Type:Screw Terminal Block
Output Voltage:48 VDC
Output Current (Channel 1):8.3 A
Output Current:8.30 A
Features
PFC Function:Yes
Minimum Isolation Voltage:3000V
Efficiency:91%
Power Rating:398.4 W
