48V 1.92A 92.2W LPS Ultra Slim Step Shape 4SU DIN Rail Power Supply
48 Volts DC @ 1.92 AmpsFeatures
- Standard model: Pass LPS with a narrower output adjustable range
- Ultra Slim design with 70mm width (4SU)
- Universal input 85-264VAC (277VAC operational)
- No load power consumption <0.3W
- Isolation class II
- Pass LPS (limited power source)
- DC output voltage adjustable
- Protections: Short circuit, Overload, Over voltage
- Cooling by free air convection (working temperature: -30 to +70°C)
- DIN rail TS-35/7.5 or 15 mountable
- LED indicator for power on
- 3 year warranty
Specifications
- Input voltage: 85 to 264 VAC @ 47-63 Hz
- Size: 2.76" x 3.54" x 2.15"
- Certification: UL, CUL, TUV, CB, CE, LPS
Applications
- Household control systems
- Automation of Buildings
- Industrial Control Systems
- Automation of manufacturing processes
- Electro-mechanical apparatus
Overview
Product Identification
Product Type:DIN Rail Power Supply SMPS
Manufacturer Series:HDR-100
Compliance
Agency Approvals: CB, CE, CUL, EAC, EN, TUV, UL
Dimensions & Appearance
Color:Black
Depth:2.15 in.
Width:2.76 in.
Height:3.54 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:85 VAC to 264 VAC
Maximum Input Current:3 A
Output
Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Voltage:48 VDC
Additional Output Voltages (VDC):N/A
Output Current:1.92 A
Features
PFC Function:No
Low Power Source (LPS):Yes
Efficiency:90%
Power Rating:92.2 W
