24V 20A 480W Three Phase Industrial DIN Rail Power Supply
24 Volts @ 20 AmpsSpecifications
- Output Power: 480 watts
- Input Voltage: 3-phase 340-550 VAC @ 47-63 Hz; 480-780 VDC
- Input Current @ max load: 0.85A
- Size: 3.37"W x 4.93"H x 5.06"D
- Weight: 3.58 lbs.
- Certification: UL, CB, CE
Features
- Three-phase 340-550VAC wide range input (Dual phase operation possible)
- Width only 85.5mm
- Built-in active PFC function compliance to EN61000-3-2
- High efficiency 92.5% and low power dissipation
- Protections: Short circuit, overload, over voltage, over temperature
- Cooling by free air convection
- Built-in constant current limiting circuit
- Can be installed on DIN rail TS-35/7.5 or 15
- UL508 (industrial control equipment) approved
- EN61000-6-2 (EN50082-2) industrial immunity level
- 3 year warranty
Applications
- Industrial control systems
- Semiconductor fabrication equipment
- Factory automation
- Electro-mechanical apparatus
Product Identification
Product Type:DIN Rail Power Supply SMPS
Manufacturer Series:TDR-480
Compliance
Agency Approvals: CB, CE, EAC, EN, UL
Dimensions & Appearance
Color:Silver
Depth:3.37 in.
Width:4.93 in.
Height:5.06 in.
Operating conditions
Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C
Input
Input Frequency:47 Hz to 63 Hz
Input Voltage:340 VAC to 550 VAC
Maximum Input Current:0.85 A
Output
Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Voltage:24 VDC
Additional Output Voltages (VDC):N/A
Output Current:20 A
Features
Low Power Source (LPS):No
PFC Function:Yes
Efficiency:92.5%
Power Rating:480 W
