40 mm x 40 mm x 15 mm Tube Axial Fan 24 VDC Ball Bearing 6.8CFM 29dBA 12" Wires (3)

Features

  • Voltage Rating: 24 VDC
  • Height: 40 mm
  • Width: 40 mm
  • Depth: 15 mm
  • Air Flow (CFM): 6.8
  • Bearing: Ball
  • Current Rating: 60 mA
  • Power Rating: 1.44 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 29
  • Termination: 12" Wires (3)
  • Product Type: 40mm x 40mm DC Fan
  • Speed: 6000 rpm
  • Maximum Pressure: 0.16 in.
  • Additional Features: Open Collector Alarm Output
  • Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 6000 rpm.

Product Identification

Additional Feature:Open Collector Alarm Output
Product Type:DC Fan

Compliance

RoHS Status:ROHS Compliant
Compliance:Compliance Docs
Agency Approvals: CE, CUL, TUV, UKCA, UL

Dimensions & Appearance

Depth:15 mm
Height:40 mm
Width:40 mm

Features

Bearing:Ball
Maximum Pressure:0.16 in.
Motor Drive Type:Brushless DC, Auto Restart, Polarity Protected
Power Rating:1.44 W
Noise (dBA):29
Voltage Rating:24 VDC
Air Flow (CFM):6.8
Speed:6000 rpm
Termination:12" Wires (3)
Current Rating:60 mA
,
