40 mm x 40 mm x 10.5 mm Tube Axial Fan 12 VDC Ball Bearing 9.2CFM 33.4dBA 12" Wires

Features

  • Voltage Rating: 12 VDC
  • Height: 40 mm
  • Width: 40 mm
  • Depth: 10.5 mm
  • Air Flow (CFM): 9.2
  • Bearing: Ball
  • Current Rating: 70 mA
  • Power Rating: 0.84 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 33.4
  • Termination: 12" Wires
  • Product Type: 40mm x 40mm DC Fan
  • Speed: 8000 rpm
  • Maximum Pressure: 0.2 in.
  • Additional Features: Open Collector Alarm Output
  • Motor Drive Type: Brushless DC, Auto Restart, Impedance Protected, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 8000 rpm.

Product Identification

Additional Feature:Open Collector Alarm Output
Product Type:DC Fan

Compliance

RoHS Status:ROHS Compliant
Compliance:Compliance Docs
Agency Approvals: CE, CUL, TUV, UKCA, UL

Dimensions & Appearance

Depth:10.5 mm
Height:40 mm
Width:40 mm

Features

Bearing:Ball
Air Flow (CFM):9.2
Noise (dBA):33.4
Maximum Pressure:0.2 in.
Motor Drive Type:Brushless DC, Auto Restart, Impedance Protected, Polarity Protected
Power Rating:0.84 W
Voltage Rating:12 VDC
Termination:12" Wires
Speed:8000 rpm
Current Rating:70 mA
,
