36V 13.3A 478.8W Constant Voltage and Constant Current LED Driver Model A

36 Volts @ 13.3 Amps

Features

    Model A - Current and voltage output adjustable through a built-in potentiometer
  • Wide input range: 180 to 528 VAC
  • Constant voltage and constant current mode output
  • Metal housing with Class I design
  • Built-in active PFC function
  • IP65 rated for indoor or outdoor installations
  • Typical lifetime: >50,000 hours
  • 5 year warranty

Specifications

  • Output voltage: 36 VDC
  • Output current: 13.3 A
  • Voltage adjustment range: 30.6 to 37.8 V
  • Constant current region: 18 - 36 VDC
  • Current adjustment range: 6.6 to 13.3 A
  • Output power: 478.8 W
  • Input voltage: 180 - 528 VAC @ 47-63 Hz; or 254 - 747 VDC
  • Efficiency: 94.5%
  • Size: 10.3"L x 4.9"W x 1.7"H
  • Load regulation: ±0.5%
  • Line regulation: ± 0.5%
  • Operating temperature: -40 to +85°C
  • Agency approvals: UL, CUL, FCC

Applications

  • LED greenhouse lighting
  • LED stadium lighting
  • LED mining lighting
  • Type "HL" for use in Class I, Division 2 hazardous (Classified) locations

Product Identification

Product Type:Auto Switching SMPS
Manufacturer Series:HVG-480

Compliance

Agency Approvals: CUL, EAC, EN, FCC, UL

Dimensions & Appearance

Style:Enclosed
Color:Silver
Height:1.72 in.
Length:10.31 in.
Width:4.92 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:85°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:180 VAC to 528 VAC
Maximum Input Current:1.52 A

Output

Number of Outputs:1
Output Connector Type:Stripped and Tinned
Output Voltage:36 VDC
Output Range:30.6 VDC to 37.8 VDC
Output Current:13.30 A

Features

PFC Function:Yes
Minimum Isolation Voltage:3750V
IP Rating:IP65
Efficiency:94.5%
Power Rating:478.8 W
,
