350.4W ENCLOSED DC/DC CONVERTER

48 Volts @ 7.3 Amps


Features:

  • Input Voltage Range: 36V-72V
  • 100% Full load burn-in test
  • Protections: Short-circuit, Overload, Overvoltage, Overtemperature
  • Number of terminal pins: 9
  • Ripple & Noise: 150mVp-p
  • Size: 8.5"L x 4.5"W x 2.0"H
  • 2-year warranty

Product Identification

Type:Non-Inverting, Step Up, Step Down
Product Type:DC to DC Power Supply SMPS
Manufacturer Series:SD-350

Compliance

Agency Approvals: CE, EAC, EN, TUV, TUV, CE, EN, EAC

Dimensions & Appearance

Height:2 in.
Width:4.5 in.
Length:8.5 in.
Mounting:Enclosed

Operating conditions

Minimum Operating Temperature:-20°C
Maximum Operating Temperature:60°C

Packaging

Package:Enclosed

Input

Input Voltage:48 VDC
Input Voltage Range:36 VDC to 72 VDC
Maximum Input Current:9 A

Output

Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Voltage:48 VDC
Additional Output Voltages (VDC):N/A
Output Current:7.30 A

Features

Switching Regulator:No
Pins:9
Efficiency:82%
Power Rating:350.4 W
,
