35 mm x 35 mm x 10 mm Tube Axial Fan 12 VDC Ball Bearing 6CFM 32dBA 12" Wires (3)

Features

  • Voltage Rating: 12 VDC
  • Height: 35 mm
  • Width: 35 mm
  • Depth: 10 mm
  • Air Flow (CFM): 6
  • Bearing: Ball
  • Current Rating: 650 mA
  • Power Rating: 7.8 W
  • Agency Approvals: UL, CUL, CE
  • Noise (dBA): 32
  • Termination: 12" Wires (3)
  • Product Type: 35mm x 35mm DC Fan
  • Speed: 8000 rpm
  • Maximum Pressure: 0.17 in.
  • Additional Features: Open Collector Alarm Output
  • Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 8000 rpm.

,
