320 Watt 36 Volt 8.9 Amp Fully Potted Enclosed Industrial Switching Power Supply

36 Volts @ 8.9 Amps

Features

  • Standard Model: Voltage output and current output can be adjusted through internal potentiometer
  • Universal AC input / Full range(up to 305VAC)
  • Built-in active PFC function
  • High efficiency up to 94%
  • Fanless design, cooling by free air convection
  • -55°C to +70° wide operating range
  • Aluminum case and filling with heat-conducted silicone
  • IP65 design
  • Meet 6KV surge immunity level
  • Withstand 10G vibration test
  • Operating altitude up to 5000 meters
  • Protections: Short circuit, Overload, Over voltage, Over temperature
  • 6 years warranty

Applications

  • Outdoor telecommunication equipment
  • Outdoor electronic signage and billboard
  • Petroleum plant or mine shaft facility

Product Identification

Type:Auto Switching SMPS
Manufacturer Series:HEP-320

Compliance

Agency Approvals: CB, CE, CUL, EAC, EN, UL

Dimensions & Appearance

Style:Enclosed
Color:Silver
Height:1.72 in.
Width:3.54 in.
Length:9.96 in.

Operating conditions

Minimum Operating Temperature:-55°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 305 VAC
Maximum Input Current:3.5 A

Output

Number of Outputs:1
Output Voltage (Channel 1):36 VDC
Output Connector Type:Stripped and Tinned
Output Voltage:36 VDC
Output Current (Channel 1):8.9 A
Output Current:8.90 A

Features

PFC Function:Yes
Minimum Isolation Voltage:3750V
Efficiency:94%
Power Rating:320.4 W
,
