3150mA 150W Single Ouput LED Power Supply

Specifications

  • Output Rated Current: 3150mA
  • Output Power (W): 151.2
  • Ripple & Noise (V p-p): 1
  • Line Regulation : ± 1%
  • Efficiency: 90%
  • Size (L x W x H) inches: 7.51 X 2.48 X 1.47
  • Constant current design
  • 180 - 305 input only
  • Protections: short circuit, over voltage, over temperature
  • Cooling by free air convention
  • 2 year warranty

Product Identification

Product Type:Auto Switching SMPS
Manufacturer Series:LPC-150

Compliance

Agency Approvals:EN, EAC, CE

Dimensions & Appearance

Style:Enclosed
Color:White
Height:1.47 in.
Width:2.48 in.
Length:7.51 in.

Operating conditions

Minimum Operating Temperature:-25°C
Maximum Operating Temperature:50°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:180 VAC to 305 VAC
Maximum Input Current:1.7 A

Output

Number of Outputs:1
Output Connector Type:Stripped and Tinned
Output Range:24 VDC to 48 VDC
Output Voltage:See Output Range
Output Current:3.15 A

Features

PFC Function:No
Minimum Isolation Voltage:3000V
IP Rating:IP67
Efficiency:90%
Power Rating:151.2 W
,
