300 mA DC-DC Constant Current Encapsulated Buck-Boost LED driver

Features

  • Output voltage range: 2 Volts DC to 40 Volts DC
  • Input voltage range: 9 Volts DC to 36 Volts DC
  • Efficiency: 90%
  • Wire style connection
  • Built in EMI filter, PWM and remote ON/OFF control
  • Protections: short circuit, over temperature
  • Cooling by free air convection
  • Low cost, high reliability
  • Compact size, fully encapsulated with IP67 level
  • Suitable for driving illumination LED
  • 3 year warranty

    • Product Identification

    Manufacturer Series:LDB-L
    Product Type:Constant Current Buck-Boost SMPS

    Compliance

    Agency Approvals:CE, FCC, EN, EAC

    Dimensions & Appearance

    Style:Encapsulated
    Color:Black
    Height:0.48 in.
    Width:0.8 in.
    Length:1.25 in.

    Operating conditions

    Minimum Operating Temperature:-40°C
    Maximum Operating Temperature:71°C

    Input

    Input Frequency:N/A
    Input Voltage:9 VDC to 36 VDC
    Maximum Input Current:1.07 A

    Output

    Number of Outputs:1
    Output Range:2 VDC to 40 VDC
    Output Current:0.30 A
    Output Connector Type:Wires
    Output Voltage:See Output Range

    Features

    PFC Function:No
    IP Rating:IP67
    Minimum Isolation Voltage:N/A
    Efficiency:90%
    Power Rating:N/A
    ,
