30 mm x 30 mm x 10.5 mm Tube Axial Fan 12 VDC Ball Bearing 5CFM 30.2dBA 12" Wires (4)
Features
- Voltage Rating: 12 VDC
- Height: 30 mm
- Width: 30 mm
- Depth: 10.5 mm
- Air Flow (CFM): 5
- Bearing: Ball
- Current Rating: 120 mA
- Power Rating: 1.44 W
- Agency Approvals: UL, CUL, CE
- Noise (dBA): 30.2
- Termination: 12" Wires (4)
- Product Type: 30mm x 30mm DC Fan
- Speed: 11000 rpm
- Maximum Pressure: 0.21 in.
- Additional Features: Open Collector Tach Output, PWM
- Motor Drive Type: Brushless DC, Auto Restart, Impedance Protected, Polarity Protected
Overview
Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 11000 rpm.
Product Identification
Additional Feature:Open Collector Tach Output, PWM Output
Product Type:DC Fan
Compliance
Dimensions & Appearance
Depth:10.5 mm
Height:30 mm
Width:30 mm
Features
Bearing:Ball
Maximum Pressure:0.21 in.
Motor Drive Type:Brushless DC, Auto Restart, Impedance Protected, Polarity Protected
Voltage Rating:12 VDC
Noise (dBA):30.2
Power Rating:1.44 W
Air Flow (CFM):5
Termination:12" Wires (4)
Speed:11000 rpm
Current Rating:120 mA
