30 mm x 30 mm x 10.5 mm Tube Axial Fan 12 VDC Ball Bearing 4CFM 28.4dBA 12" Wires (3)

Features

  • Voltage Rating: 12 VDC
  • Height: 30 mm
  • Width: 30 mm
  • Depth: 10.5 mm
  • Air Flow (CFM): 4
  • Bearing: Ball
  • Current Rating: 120 mA
  • Power Rating: 1.44 W
  • Agency Approvals: UL, CUL, CE
  • Noise (dBA): 28.4
  • Termination: 12" Wires (3)
  • Product Type: 30mm x 30mm DC Fan
  • Speed: 9000 rpm
  • Maximum Pressure: 0.18 in.
  • Additional Features: Open Collector Tach Output
  • Motor Drive Type: Brushless DC, Auto Restart, Impedance Protected, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 9000 rpm.

,
