2-Conductor 20AWG Unshielded Multi-Conductor Cable 100-Foot Reel UL2464

Features:

• Unshielded multi-conductors
• Annealed stranded tin copper conductors
• 2 conductors
• Colors: Black, White
• 20 AWG unshielded wire (10 x 30 strand)
• Gray PVC jacket
• Insulation Material: PVC
• Insulation Thickness: 0.016"
• Rated 300V Temp: 80°C (UL 2464); 75°C (CM)
• Nominal outer diameter: 0.194"
• UL 2464, CM, CSA, FT1, UL VW-1
• Reel length: 100 feet

Overview

Multi-conductor cable contains individually jacketed conductors within an overall PVC jacket. This model features two 20 AWG conductors and is unshielded. It is ideal for communication and control applications.
