25W Dual Output DC-DC Converter


Output: ±5 Volts @ ±2.5 Amps

Features:
  • Input voltage range: 9-18VDC
  • Built-in EMI filter
  • Cooling by free air convection
  • 100% burn-in test
  • 1000VDC I/O isolation
  • Six-sided shielded metal case
  • Protections: Short-circuit, overload
  • Efficiency: 80%
  • Compact size: 2.0"L x 2.0"W x 0.82"H
  • 8-pin package
  • Weight: 3.88 oz. (110 grams)
  • 2-year warranty

    • Product Identification

    Type:Step Down
    Manufacturer Series:DKA30
    Product Type:DC-DC Dual Output Converter SMPS

    Compliance

    Agency Approvals: EAC, EN, FCC, UKCA, CE, CE, FCC, EN, EAC, UKCA

    Dimensions & Appearance

    Color:Black
    Height:0.82 in.
    Width:2 in.
    Length:2 in.

    Operating conditions

    Minimum Operating Temperature:-25°C
    Maximum Operating Temperature:85°C

    Input

    Input Voltage Range:9 VDC to 18 VDC
    Input Voltage:12 VDC

    Output

    Number of Outputs:2
    Additional Output Voltages (VDC):-5 VDC
    Output Voltage:5 VDC
    Output Current:2.50 A

    Features

    Pins:7
    Power Rating:25 W
    ,
