254 mm x 254 mm x 89 mm Tube Axial Fan 24 VDC Ball Bearing 690CFM 47.4dBA Terminals

Features

  • Voltage Rating: 24 VDC
  • Height: 254 mm
  • Width: 254 mm
  • Depth: 89 mm
  • Air Flow (CFM): 690
  • Bearing: Ball
  • Current Rating: 1500 mA
  • Power Rating: 36 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 47.4
  • Termination: Terminals
  • Product Type: 254mm x 254mm DC Fan
  • Speed: 2000 rpm
  • Maximum Pressure: 0.58 in.
  • Additional Features: Die Cast Aluminum Frame Black, PBT Impeller
  • Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Electronically Protected, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 2000 rpm.

,
