254 mm x 254 mm x 89 mm Tube Axial Fan 115 VAC Ball Bearing 620CFM 63dBA 12" Wires

Features

  • Voltage Rating: 115 VAC
  • Height: 254 mm
  • Width: 254 mm
  • Depth: 89 mm
  • Air Flow (CFM): 620
  • Bearing: Ball
  • Current Rating: 826 mA
  • Power Rating: 95 W
  • Agency Approvals: UL, CUL, TUV
  • Noise (dBA): 63
  • Termination: 12" Wires
  • Product Type: 254mm x 254mm AC Fan
  • Speed: 2200 rpm
  • IP Rating: IP56
  • Maximum Pressure: 0.27 in.
  • Motor Drive Type: AC, Capacitor Induction, Thermally Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 2200 rpm.

Product Identification

Product Type:AC Fan

Compliance

RoHS Status:ROHS Compliant
Compliance:Compliance Docs
Agency Approvals: CUL, TUV, UL

Dimensions & Appearance

Depth:89 mm
Height:254 mm
Width:254 mm

Features

Bearing:Ball
IP Rating:IP56
Maximum Pressure:0.27 in.
Motor Drive Type:AC, Capacitor Induction, Thermally Protected
Speed:2200 rpm
Noise (dBA):63
Air Flow (CFM):620
Termination:12" Wires
Voltage Rating:115 VAC
Power Rating:95 W
Current Rating:826 mA
,
