254 mm x 254 mm x 89 mm Tube Axial Fan 115 VAC Ball Bearing 547CFM 55dBA Terminals

Features

  • Voltage Rating: 115 VAC
  • Height: 254 mm
  • Width: 254 mm
  • Depth: 89 mm
  • Air Flow (CFM): 547
  • Bearing: Ball
  • Current Rating: 287 mA
  • Power Rating: 33 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 55
  • Termination: Terminals
  • Product Type: 254mm x 254mm AC Fan
  • Speed: 1650 rpm
  • Maximum Pressure: 0.39 in.
  • Motor Drive Type: AC, Capacitor Induction, Thermally Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 1650 rpm.

Product Identification

Product Type:AC Fan

Compliance

Agency Approvals: CE, CUL, TUV, UKCA, UL

Dimensions & Appearance

Depth:89 mm
Height:254 mm
Width:254 mm

Features

Bearing:Ball
Motor Drive Type: Capacitor Induction, Thermally Protected, AC
Air Flow (CFM):547
Noise (dBA):55
Speed:1650 rpm
Maximum Pressure:0.39 in.
Voltage Rating:115 VAC
Termination:Terminals
Power Rating:33 W
Current Rating:287 mA
,
