252W 4.2V 60A Single Output Switchable Power Supply

4.2 Volts @ 60 Amps

Features

  • AC input range selectable by a switch
  • Withstand 300 VAC surge input for 5 seconds
  • No load power consumption <0.75W
  • 1U low profile
  • High operating temperature, up to 70°C
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • Built-in cooling fan, ON-OFF control
  • Compliance to UL 60950-1
  • Withstand 5G vibration test
  • High efficiency, long life and high reliability
  • LED indicator for power on
  • 100% full load burn-in test
  • 3 year warranty

Applications

  • Industrial automation machinery
  • Industrial control system
  • Mechanical and electrical equipment
  • Electronic instruments, equipment or apparatus

Related Products

Overview

Product Identification

Type:Auto Switching SMPS
Manufacturer Series:LRS-350

Compliance

Agency Approvals: BSMI, CB, CE, CUL, EAC, UL, IEC/EN 61558-1

Dimensions & Appearance

Style:Enclosed
Color:Silver
Height:1.2 in.
Width:4.5 in.
Length:8.5 in.

Operating conditions

Minimum Operating Temperature:-25°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 132 VAC, 180 VAC to 264 VAC
Maximum Input Current:6.8 A

Output

Number of Outputs:1
Output Voltage (Channel 1):4.2 VDC
Output Voltage:4.2 VDC
Output Connector Type:Screw Terminal Block
Output Current (Channel 1):60 A
Output Current:60 A

Features

PFC Function:No
Minimum Isolation Voltage:3000V
Efficiency:81.5%
Power Rating:252 W
,
