25 Watt 50 Volt 0.5 Amp Constant Current Enclosed LED Power Supply

500 mA, Constant Current Region: 30V - 50V

The PLM-25E is a 25 watt economical AC/DC LED power supply series. Incorporating built-in active PFC, the PLM-25E provides a high power factor value greater than 0.9. In addition to the low no load power consumption below 0.5 watts, and the setup time less than 500ms, the PLM-25E complies with the ErP regulation required by European Union for lighting fixtures.

PLM-25E is a class 2 (without FG pin) power unit housed with the UL 94V-0 rated flame retardant plastic case. The I/O terminals are designed with screw-less clamp style terminal block that greatly simplifies the wiring installation. The PLM-25E series operates from 180-295VAC and this series is a constant current output design, supplying 500 mA of current.

Features

  • 180-295 volt AC input
  • No load output voltage: 56 Volts (max.)
  • Built-in active PFC function
  • Constant current design
  • Protections: Short circuit
  • Cooling by free air convection
  • Fully isolated plastic case
  • Class II power unit, no FG
  • No load power consumption <0.5W
  • High reliability, low cost
  • Non-Class 2
  • 2 year warranty

    Applications

  • Indoor LED lighting
  • LED office lighting
  • LED commercial lighting
  • LED decorative lighting
  • Moving sign

    • Product Identification

    Product Type:Auto Switching SMPS
    Manufacturer Series:PLM-25E

    Compliance

    Agency Approvals:CB, CE, EN, ENEC, EAC, CCC

    Dimensions & Appearance

    Style:Enclosed
    Color:White
    Height:0.86 in.
    Width:1.49 in.
    Length:5.7 in.

    Operating conditions

    Minimum Operating Temperature:-30°C
    Maximum Operating Temperature:45°C

    Input

    Input Frequency:47 Hz to 63 Hz
    Maximum Input Current:0.15 A
    Input Voltage:180 VAC to 295 VAC

    Output

    Number of Outputs:1
    Output Connector Type:Screw Terminal Block
    Output Current:0.50 A
    Output Range:30 VDC to 50 VDC
    Output Voltage:See Output Range

    Features

    PFC Function:Yes
    IP Rating:IP30
    Minimum Isolation Voltage:3750V
    Efficiency:86%
    Power Rating:25 W
    ,
