24W 350mA 49-70 VDC Constant Current Mode Enclosed LED Driver with Dimming

Constant Current Region: 49-70 Volts DC @ 0.35 Amps

Features

  • 2 in 1 dimming (0-10VDC and 10V PWM)
  • Flicker-free design
  • Plastic housing design with class II design
  • Built-in active PFC function
  • No load power consumption <0.5W
  • 3 year warranty

Specifications

  • Input voltage: 90 to 295 VAC @ 47-63 Hz
  • Isolation voltage: 3750 VAC
  • Size: 4.33" x 2.95" x 0.87"
  • Certification: UL, CUL, SELV, ENEC, CCC, CB, CE

Applications

  • LED panel lighting
  • Indoor LED lighting
  • LED flood lighting

Product Identification

Product Type:Auto Switching SMPS
Manufacturer Series:IDLC-25

Compliance

Agency Approvals:UL, CUL, CB, CE, EN, ENEC, EAC, CCC

Dimensions & Appearance

Style:Enclosed
Color:White
Height:0.87 in.
Width:2.95 in.
Length:4.33 in.

Operating conditions

Minimum Operating Temperature:-20°C
Maximum Operating Temperature:90°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:90 VAC to 295 VAC
Maximum Input Current:0.4 A

Output

Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Current:0.35 A
Output Voltage:See Output Range
Output Range:49 VDC to 70 VDC

Features

PFC Function:Yes
IP Rating:IP20
Minimum Isolation Voltage:3750V
Efficiency:82%
Power Rating:24.5 W
,
