240W Single Output Industrial DIN RAIL Power Supply


Output: 48 Volts @ 5 Amps

Features:

  • Input: 180-550VAC @ 47-63Hz, or 254-780VDC
  • Single and two phase wide input range 180~550VAC
  • Built-in active PFC circuit compliance to EN61000-3-2
  • High efficiency 91% and low power dissipation
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • Cooling by free air convection
  • Can be installed on DIN rail TS-35/7.5 or 15
  • UL 508 (industrial control equipment) approved
  • EN61000-6-2 (EN50082-2) industrial immunity level
  • Built-in DC OK relay contact
  • 100% full load burn-in test

Product Identification

Product Type:DIN Rail Power Supply SMPS
Manufacturer Series:WDR-240

Compliance

Agency Approvals: CB, CE, EAC, EN, UL

Dimensions & Appearance

Color:Silver
Depth:2.48 in.
Height:4.47 in.
Width:4.93 in.

Operating conditions

Minimum Operating Temperature:-30°C
Maximum Operating Temperature:70°C

Input

Input Frequency:47 Hz to 63 Hz
Input Voltage:180 VAC to 550 VAC
Maximum Input Current:2 A

Output

Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Voltage:48 VDC
Additional Output Voltages (VDC):N/A
Output Current:5 A

Features

Low Power Source (LPS):No
PFC Function:Yes
Efficiency:91%
Power Rating:240 W
,
