230/400VAC 2-Phase+N DIN Rail Surge Protection Device MOV 275V MCOV 40kA IMAX

This surge protection device (SPD) designed for 230 or 400 VAC 2-phase+N AC Power circuits and uses MOV technology. It features 40kA surge current rating per module and is UL1449 Type 4AC. It has a visual fault indicator, remote contacts, and comes with a 10-year warranty.

Specifications

  • Protection Mode(s): Common Mode or Differential Mode
  • Power SPD Type: UL1449 TYPE 4AC
  • VOLTS: 400/230 V
  • AC voltage systems
  • Phase: 2
  • Amps: n/a
  • Ambient Temperature: -35℃C to +60℃C
  • Modes: L-L, L-N, L-G, N-G
  • VPR: (V): n/a
  • MCOV: (V): 275
  • IN: (kA): 20
  • SCCR: (kA): n/a
  • IMAX: (kA): 40
  • limp: 4 kA
  • Technology: MOV
  • Network Configuration: 2-Phase+N
  • Connection Method: Screw Terminal (8 to 12 AWG)
  • Mounting: DIN RAIL
  • Material: Thermoplastic UL94-V0
  • NEMA Rating (IP Rating): NEMA 2 (IP20)
  • Fail-Safe Behavior

,
