20W DC-DC Regulated Converter DIP Package 24V Nominal Input 12V Output

Output Voltage @ Output Current: 12V @ 1.666A

Features:

  • DIP24 package with industry standard pinout
  • 2:1 wide input range
  • No minimum load required
  • Comply to EN55032 radiated Class A without additional components
  • High efficiency up to 89%
  • Protections: Short circuit (Continuous) / Overload
  • 1.5kVDC I/O isolation
  • Remote ON/OFF control
  • 3 years warranty

Applications

  • Outdoor and commercial LED Lighting
  • Telecom/Datacom system
  • Wireless network
  • Industrial control facility
  • Instrument
  • Analyzer
  • Detector
  • Data switch

Product Identification

Type:Isolated
Product Type:DC-DC Regulated Single Output Converter SMPS
Manufacturer Series:SCW20

Dimensions & Appearance

Height:0.48 in.
Width:0.80 in.
Length:1.25 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:80°C

Input

Input Voltage:24 VDC
Input Voltage Range:18 VDC to 36 VDC
Maximum Input Current:0.957 A

Output

Number of Outputs:1
Output Connector Type:DIP-24
Output Voltage:12 VDC
Additional Output Voltages (VDC):N/A
Output Current:1.666 A

Features

Pins:9
Efficiency:87%
Power Rating:20 W
,
