205 mm x 205 mm x 72 mm Tube Axial Fan 115 VAC Ball Bearing 590CFM 67.4dBA Terminals

Features

  • Voltage Rating: 115 VAC
  • Height: 205 mm
  • Width: 205 mm
  • Depth: 72 mm
  • Air Flow (CFM): 590
  • Bearing: Ball
  • Current Rating: 695 mA
  • Power Rating: 80 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 67.4
  • Termination: Terminals
  • Product Type: 205mm x 205mm AC Fan
  • Speed: 3000 rpm
  • IP Rating: IP69K
  • Maximum Pressure: 0.86 in.
  • Motor Drive Type: AC Capacitor Induction, Outer Rotor, Single-Phase, Thermally Protected, IP69K

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 3000 rpm.

,
