201.6W Enclosed DC/DC Converter 48V 4.2A Output 72-144VDCin
48 Volts DC @ 4.2 AmpsFeatures
- Input Voltage Range: 72V-144V
- 100% Full load burn-in test
- Protections: Short-circuit, Overload, Overvoltage, Overtemperature
- Number of terminal pins: 9
- Ripple & Noise: 120mVp-p
- Size: 8.5"L x 4.5"W x 2.0"H
- 2-year warranty
Product Identification
Type:Step Down
Product Type:DC to DC Power Supply SMPS
Manufacturer Series:SD-200
Compliance
Agency Approvals: CB, CE, EAC, EN, TUV, TUV, CB, CE, EN, EAC
Dimensions & Appearance
Mounting:Enclosed
Height:2 in.
Width:4.5 in.
Length:8.5 in.
Operating conditions
Minimum Operating Temperature:-20°C
Maximum Operating Temperature:60°C
Packaging
Package:Enclosed
Input
Input Voltage Range:72 VDC to 144 VDC
Input Voltage:96 VDC
Maximum Input Current:3.5 A
Output
Number of Outputs:1
Output Connector Type:Screw Terminal Block
Output Voltage:48 VDC
Additional Output Voltages (VDC):N/A
Output Current:4.20 A
Features
Switching Regulator:Yes
Pins:9
Efficiency:90%
Power Rating:201.6 W
