201.6W Enclosed DC/DC Converter



48 Volts @ 4.2 Amps

Features

  • Input Voltage Range: 36V-72V
  • 100% Full load burn-in test
  • Protections: Short-circuit, Overload, Overvoltage, Overtemperature
  • Number of terminal pins: 9
  • Ripple & Noise: 200mVp-p
  • Size: 8.5"L x 4.5"W x 2.0"H
  • 2-year warranty

    • Product Identification

    Type:Non-Inverting, Step Up, Step Down
    Product Type:DC to DC Power Supply SMPS
    Manufacturer Series:SD-200

    Compliance

    Agency Approvals: CE, EAC, EN, TUV, TUV, CE, EN, EAC

    Dimensions & Appearance

    Mounting:Enclosed
    Height:2 in.
    Width:4.5 in.
    Length:8.5 in.

    Operating conditions

    Minimum Operating Temperature:-20°C
    Maximum Operating Temperature:60°C

    Packaging

    Package:Enclosed

    Input

    Input Voltage:48 VDC
    Input Voltage Range:36 VDC to 72 VDC
    Maximum Input Current:5 A

    Output

    Number of Outputs:1
    Output Connector Type:Screw Terminal Block
    Output Voltage:48 VDC
    Additional Output Voltages (VDC):N/A
    Output Current:4.20 A

    Features

    Switching Regulator:Yes
    Pins:9
    Efficiency:86%
    Power Rating:201.6 W
    ,
