200W General Type Variable Frequency Drive with PFC Function for 200-240V Motor

MEAN WELL

Jameco Part #:

Manufacturer #:

Primary datasheet

Non Cancelable

Non Returnable

Product Price:

$38.950

In Stock: 0

Quantity	Unit Price	You Save	Discount
1+	$38.950	-	-
5+	$36.550	2.40	6.16%
25+	$34.650	4.30	11.04%

Features

Universal AC input: 90 to 264 VAC with built-in PFC function
Controllable with external controller
Fanless design for no-noise and extended life cycle
High surge current of 200% for up to 5 seconds
Protections: Short circuit, over current
Provides multiple sensors for control:

Current sensor - motor torque control
DC bus voltage sensor - OVP/UVP
Temperature sensor - OTP

-30 to +70°C wide operating temperature range
Suitable for three phase motor drive (BLDC, Induction motor, SynRM)
3-year warranty

Overview

The VFD-200C-230 is a variable frequency drive that can be controlled with external PWM controller. The input range is from 90 VAC to 264 VAC which is suitable for a multitude of installations. This VFD is able to deliver 200% peak load and is of a fanless design. It is well suited for three-phase motor drive such as BLDC, induction motor, and SynRM applications.

Technical Specifications

Output voltage range: Three-phase line-to-line 0-240V, suited for 200-240V class motor
Output Capacity: 200 W
Rated Current: 0.8 A
Peak Current: 1.6 A
DC Bus Voltage: 380 VDC ±5

Applications

HVAC
Fan
Pump
Automatic door
Air conditioning
Conveyor
Medical device
Fitness equipment
