200W 150V Precision DC Electronic Load (DL3021A)

Features

• Single output, 150 V/40 A/30 kHz, total power up to 200 W
• Dynamic mode: up to 30 kHz
• Adjustable current rising speed: 0.001 A/µs to 5 A/µs
• Min. readback resolution: 0.1 mV, 0.1 mA
• 4.3-inch TFT LCD
• Over-voltage/over-current/overpower/over-temperature/reverse voltage protection
• 4 static modes: CC, CV, CR, CP
• 3 dynamic modes: continuous, pulsed, toggled
• Battery test function, OCP test, OPP test, factory test function, etc.
• Short-circuit test function
• Power-off memory function
• Built-in RS232/USB/LAN communication interface

Overview

The DL3000 is a high-performing, low-cost programmable DC electronic load. The DL3000 series offers a variety of interfaces for remote connectivity to fulfill your varied test requirements. It has an intuitive interface and excellent performance specs. It has numerous applications in a variety of fields, including fuel cells, aircraft, and automotive electronics.
