200 MHz 2-Channel Mixed Signal Oscilloscope 2GSa/s 12-bit High-Resolution 100Mpts 12.1" Touch Screen
Features
- 200 MHz model
- 12-bit high resolution
- Sampling rate up to 2 GSa/s
- Memory depth up to 100 Mpts
- Waveform capture rate up to 500,000 wfm/s (Sequence mode)
- Noise floor as low as 70 µVrms at 200 MHz full bandwidth
Overview
SIGLENT’s SDS1000X HD series high resolution digital storage oscilloscopes are based on 2 GSa/s, 12-bit Analog-Digital Converters and front ends with excellent noise floor performance. They are available in bandwidths of 200 MHz and 100 MHz, have maximum record length of 100 Mpts, and display 2/4 analog channels + 16 digital channels mixed signal analysis ability.
The SDS1000X HD series utilizes Siglent’s SPO technology with a waveform capture rate up to 120,000 wfm/ s (normal mode, up to 500,000 wfm/s in Sequence mode), 256-level intensity grading display function and a color temperature display mode. It also has an innovative digital trigger system with high sensitivity and low jitter. The trigger system supports multiple powerful triggering modes including serial bus triggering. Tools like History waveform recording, Search and Navigate functions, Mask Test, Bode Plot, Power Analysis and allows for extended waveform records to be captured, stored, and analyzed. It also has an impressive array of measurement and math capabilities, options for a 25 MHz arbitrary waveform generator, as well as serial decoding are also some of the SDS1000X HD features.
