20 Watt DC-DC Regulated Single Output Converter

15 Volts @ 133-1333 mAmps

Features:

  • 2" 1" compact size
  • 2:1 wide input range
  • 89.5% efficiency
  • 1500VDC I/O isolation
  • Built-in remote ON/OFF control
  • Built-in trimming output
  • Built-in EMI filter
  • Protections: Short circuit / Overload / Input and Output Over voltage
  • Cooling by free air convection
  • Six-sided shield metal case
  • 100% burn-in test
  • Low cost / High reliability
  • Approvals: FCC / CE
  • 2 years warranty

Product Identification

Product Type:DC to DC Regulated Single Output Converter SMPS
Manufacturer Series:SKA20

Dimensions & Appearance

Mounting:Encapsulated
Height:0.44 in.
Width:1 in.
Length:2 in.

Operating conditions

Minimum Operating Temperature:-40°C
Maximum Operating Temperature:85°C

Packaging

Package:Enclosed Module

Input

Input Voltage Range:18 VDC to 36 VDC
Maximum Input Current:0.95 A

Output

Number of Outputs:1
Output Connector Type:PC Pins
Output Voltage:15 VDC
Additional Output Voltages (VDC):N/A
Output Current:1.333 A

Features

Pins:6
Efficiency:89.5%
Power Rating:20 W
,
