2 Row 16 Contacts Header Vertical Receptacle .100" 2.54mm Female Header Receptacle

Specifications

  • 2x8 pins
  • Gold-plated contacts
  • Height above board: 8.5mm (0.335")

Product Identification

Manufacturer Series:ValuePro

Dimensions & Appearance

Depth:5 mm
Length:20.32 mm
Body Orientation:Straight

Features

Number of Rows:2
Housing Color:Black
Contact Material:Brass
Maximum Contact Resistance:20 mOhm
Contact Plating:Gold
Number of Contacts:16
Gender:Female
Housing Material:Thermoplastic
Pitch:2.54 mm
Voltage Rating:250 VAC
Current Rating:3 A
,
