2 Pole (TS) Right Angle Gold-Plated 1/4" Phone Plug for Audio Applications
Features
- Capacitance Between Contacts: < 8.4 pF
- Capacitance Between Contacts and Shield: < 7.4 pF
- Contact Resistance: Depends on mating connector
- Insulation Resistance: > 100MΩ
- Dialectric Strength: 500V
- Current Rating: 15A/125V
- Number of Pins/Poles: 2
- Gender: Male
- Contact Material: Brass
- Contact Platng: Tin
- Shell Material: Zinc Die-Cast
- Shell Color: Nickel
- Wiring: Solder Contacts
- Plug: Nickel Plated
Overview
Suitable for guitar applications, audio cables, snakes, speakers, amplifiers and mixing desks.
The M Series 1/4 plugs feature an extremely durable nickel plated brass shell and include a sturdy plastic insert that tightens onto the cable to provide strain relief while an additional rubber boot delivers extended support. The nickel plated plug contacts and tin plated wire terminals all ensure the best possible signal flow. Additionally, a thicker thread gauge means the threads will be less prone to strip compared to other similar plugs. These connectors also feature larger solder terminals and no tool housing assembly for ease of termination.
M Series ¼" plugs meet the most recent requirements for highest density jack fields (15.88), so they can be used in a variety of applications including use with various instruments and patch bays for home or professional studios.
