180 mm x 180 mm x 65 mm Tube Axial Fan 12 VDC Ball Bearing 375CFM 53.4dBA 12" Wires

Features

  • Voltage Rating: 12 VDC
  • Height: 180 mm
  • Width: 180 mm
  • Depth: 65 mm
  • Air Flow (CFM): 375
  • Bearing: Ball
  • Current Rating: 1900 mA
  • Power Rating: 22.8 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 53.4
  • Termination: 12" Wires
  • Product Type: 180mm x 180mm DC Fan
  • Speed: 2800 rpm
  • Maximum Pressure: 0.7 in.
  • Additional Features: Die Cast Aluminum Frame Black, PBT Impeller
  • Motor Drive Type: Brushless DC, Auto Restart, Rotor Lock, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 2800 rpm.

Product Identification

Additional Feature:Die Cast Aluminum Frame Black, PBT Impeller
Product Type:DC Fan

Compliance

RoHS Status:ROHS Compliant
Compliance:Compliance Docs
Agency Approvals: CE, CUL, TUV, UKCA, UL

Dimensions & Appearance

Depth:65 mm
Height:180 mm
Width:180 mm

Features

Bearing:Ball
Motor Drive Type:Brushless DC, Auto Restart, Rotor Lock, Polarity Protected
Speed:2800 rpm
Voltage Rating:12 VDC
Maximum Pressure:0.7 in.
Termination:12" Wires
Noise (dBA):53.4
Air Flow (CFM):375
Power Rating:22.8 W
Current Rating:1900 mA
,
