176 mm x 176 mm x 89 mm Tube Axial Fan 230 VAC Ball Bearing 380CFM 63dBA 12" Wires
Features
- Voltage Rating: 230 VAC
- Height: 176 mm
- Width: 176 mm
- Depth: 89 mm
- Air Flow (CFM): 380
- Bearing: Ball
- Current Rating: 347 mA
- Power Rating: 80 W
- Agency Approvals: UL, CUL, TUV
- Noise (dBA): 63
- Termination: 12" Wires
- Product Type: 176mm x 176mm AC Fan
- Speed: 3250 rpm
- IP Rating: IP56
- Maximum Pressure: 0.76 in.
- Motor Drive Type: AC Capacitor Inductance, Thermally Protected
Overview
Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 3250 rpm.
Product Identification
Product Type:AC Fan
Compliance
Dimensions & Appearance
Depth:89 mm
Height:176 mm
Width:176 mm
Features
Bearing:Ball
Motor Drive Type:AC Capacitor Inductance, Thermally Protected
IP Rating:IP56
Noise (dBA):63
Air Flow (CFM):380
Maximum Pressure:0.76 in.
Speed:3250 rpm
Termination:12" Wires
Voltage Rating:230 VAC
Power Rating:80 W
Current Rating:347 mA
