172 mm x 150 mm x 51 mm Tube Axial Fan 24 VDC Dual Ball Bearing 310CFM 60dBA 12" Wires (4)

Features

  • Voltage Rating: 24 VDC
  • Height: 150 mm
  • Width: 172 mm
  • Depth: 51 mm
  • Air Flow (CFM): 310
  • Bearing: Dual Ball
  • Current Rating: 970 mA
  • Power Rating: 23.28 W
  • Agency Approvals: UL, CUL, TUV, CE, UKCA
  • Noise (dBA): 60
  • Termination: 12" Wires (4)
  • Product Type: 172mm x 150mm DC Fan
  • Speed: 3950 rpm
  • Maximum Pressure: 1.28/0.9 in.
  • Additional Features: Reversible Flow, PWM Speed Control, Tach Output
  • Motor Drive Type: Brushless DC, Auto Restart, Polarity Protected, Electronically Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Dual Ball bearing system of the tube axial fan is designed to operate up to 3950 rpm.

,
