172 mm x 172 mm x 51 mm Tube Axial Fan 230 VAC Ball Bearing 293CFM 61dBA Terminals

Features

  • Voltage Rating: 230 VAC
  • Height: 172 mm
  • Width: 172 mm
  • Depth: 51 mm
  • Air Flow (CFM): 293
  • Bearing: Ball
  • Current Rating: 217 mA
  • Power Rating: 50 W
  • Agency Approvals: UL, CUL
  • Noise (dBA): 61
  • Termination: Terminals
  • Product Type: 172mm x 172mm AC Fan
  • Speed: 3300 rpm
  • Maximum Pressure: 0.78 in.
  • Motor Drive Type: Capacitor Drive, Impedance Protected, Thermal Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 3300 rpm.

,
